30W Static CO2 Laser Marking Machine
Add time:2021-06-29       Source:

30W Static CO2 Laser Marking Machine


Support customized staring screen and logo, multiple language

Small and light, can carry easily, can save freight greatly.




CO2 laser to CO2 gas as a medium, CO2 and other auxiliary gases into the discharge tube in the electrode with high-voltage discharge gas to release the wavelength of 10.64um laser, the laser energy amplification, scanning and field mirror focusing by vibration mirror, under the control of the computer and laser marking control card, can be in the workpiece according to user requirements, images, text, numbers, lines, and so on. After the laser energy is amplified, under the control of computer and laser marking control card, images, words, numbers, lines and stripes can be marked on the workpiece according to the user's requirements.






SPECIFICATIONS OF IPS-LC30W S

  Model IPS-LC30W S
Laser PowerMore than 30 watt
Laser Wavelength

10.64μm/9.3μm

Linear Speed around 8000 mm/ s or more
Marking Size 75*75mm, 150*150mm, 200*200mm, 300*300mm
Min Linewidth0.01 mm
Min Font Height0.01 mm
Repetition Accuracy+-0.002 mm
Overall Power Less than 500 W
Power Supply 220V/50-60HZ/5A/1P
Laser Gun BrandSynrad / CR/ DAWEI
 Laser Gun Type

Carbon Dioxide Laser

Scanning System Digital Scanning Galvanometer with high seep motor
Focus system Two Red Light with accurate position
Cooling system Built-in Air Cooling
Flying System 10.4 inch professional fly marking system based on Android
Weight Around102KG
Overall Dimension98*107.5*63 CM
File Format SupportSupport file from CORELDRAW,AUTOCAD,PHOTOSHOP directly.  SupportAI,PLT,PCX,DXF,BMP file.
Support all fonts from windows system. Support automatic coding, serial no, batch no, real time, variable barcode and QR code and databases.
Language supportEnglish,Russian, Thailand, Korea ,Arabic ,Portuguese, etc


Applications
CO2 laser marking machine can mark a variety of non-metallic materials and some metal products, such as bamboo products, wood, paper, ABS PVC, epoxy resin, acrylic, leather, glass, construction ceramics, rubber and so on.
Oxygen resin, acrylic, leather, glass, building ceramics, rubber and so on. Widely used in pharmaceutical packaging, food packaging, beverage packaging, plastics, textiles, leather, leather, food and beverage packaging.
